How to Measure for Any Appliance

Measuring correctly is the #1 step to avoid costly mistakes, returns, and delivery headaches. Every appliance requires careful planning around width, height, depth, clearance, and door swing.

Step 1: Measure the Appliance Space

  • Width → Measure the opening side-to-side at top, middle, and bottom. Use the smallest number.

  • Height → Measure floor to top of cabinet or ceiling.

  • Depth → Measure front to back of the opening. Include countertop/lip if installing under counter.

Always leave 1–2 inches clearance on all sides for ventilation and connections.

Step 2: Account for Door Swing & Drawers

Measure in front of the space for door clearance.

For French door fridges or front-load washers, ensure doors can open fully without hitting walls/cabinets.

Dishwashers need full front clearance (24–27" beyond counter).

Step 3: Check Delivery Path

Measure all doorways, hallways, and staircases the appliance must pass through.

Watch for tight corners. Appliances are often taller or deeper than expected.

Step 4: Plan for Connections

Electrical → Check if 120V or 240V outlet is required (ranges, dryers).

Gas → For ranges/dryers, confirm working gas line and shutoff valve.

Water → For refrigerators, washers, and dishwashers, check water supply line and drain access.

Ventilation → Dryers and OTR microwaves need a vent path.

Step 5: Allow for Airflow & Service Access

  • Refrigerators need ½–1" space on sides and top.

  • Dryers need 5–6" behind for vent hose/gas line.

  • Built-in appliances should have removable panels or access points for servicing.

Golden Rule: Measure the space, measure the appliance, and measure the delivery path. Always double-check specs on the product page before purchase.

Refrigerator

Styles

Top Freezer → Budget-friendly, reliable.

Bottom Freezer → Easy access to fresh food.

Side-by-Side → Narrow doors, ice/water options.

French Door → Wide shelves, premium look.

Counter-Depth → Sleek fit with cabinetry.

Features

Ice & Water Dispenser (external vs internal)

Smart Tech (Wi-Fi, cameras inside)

Temperature Zones (deli drawers, crispers)

Fingerprint-Resistant Finishes

Energy Star Rating

Range

Fuel Types

Gas → Instant heat, flame control.

Electric → Even baking, smooth cooktops.

Induction → Fast, precise, energy-efficient.

Dual-Fuel → Gas cooktop + electric oven.

Features

Convection Oven (faster, even baking)

Air Fry / Steam Bake

Self-Cleaning Options (steam vs pyrolytic)

Expandable Elements or Bridge Burners

Smart Controls (remote preheat, monitoring)

Dishwasher

Tub Material

Stainless Steel → Quieter, more durable, dries better.

Plastic → More affordable.

Features

Noise Level (look for <50 dB)

Third Rack for utensils

Adjustable Racks for tall items

Soil Sensors for efficient cleaning

Sanitization Cycle (kills bacteria, baby bottles)

Smart Features (Wi-Fi, notifications)

Microwave Features

Types

Countertop → Affordable, portable.

Over-the-Range → Space-saving, built-in vent.

Drawer/Built-In → Sleek, premium kitchens.

Features

Wattage: 1000–1200W recommended

Sensor Cooking (auto-adjusts)

Inverter Technology (consistent power at lower heat)

Convection (bake/roast like oven)

Child Safety Lock

Washer Features

Types

Top-Load (Agitator) → Traditional, faster, rougher on clothes.

Top-Load (Impeller) → High-efficiency, gentler, more space.

Front-Load → Best cleaning, stackable, energy-efficient.

Features

Capacity → 3.5 cu. ft. for singles/couples, 4.5–5+ cu. ft. for families.

Steam Wash (removes stains, allergens)

Quick Wash Cycle

Auto-Dispense Detergent

High Spin Speeds (less dryer time)

Wi-Fi Smart Controls

Dryer Features

Fuel Types

Electric → Requires 240V outlet.

Gas → Lower long-term cost, faster drying.

Features

Capacity → Match washer’s capacity (7–7.5 cu. ft. for most families).

Steam Refresh Cycle (reduces wrinkles/odors)

Moisture Sensors (saves energy, prevents over-drying)

Wrinkle Guard (keeps tumbling after cycle)

Smart Controls (remote alerts, start/stop)

Ventless Options (for condos/apartments)
